Home ProductsDust Collector Filter Bags

Fiberglass Acrylic Nomex Polyester Filter Bag Calendering

Fiberglass Acrylic Nomex Polyester Filter Bag Calendering

  • Fiberglass Acrylic Nomex Polyester Filter Bag Calendering
Fiberglass Acrylic Nomex Polyester Filter Bag Calendering
Product Details:
Place of Origin: Made in China
Brand Name: Polyester Needle Felt Dust Collector Filter Bag
Certification: ISO9001-2015
Model Number: 5 micron Nomex Dust Collector Filter Bag (Air Filter)
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: Negotiable
Packaging Details: Carton or Woven Bag
Delivery Time: 3 days
Payment Terms: T/T, Western Union, L/C, 30% in advance,the balance before loading
Supply Ability: 1000 pcs per day
Contact Now
Detailed Product Description
Product Name: 5 Micron Nomex Dust Collector Filter Bag (Air Filter) Material: Polyester/electric Fiber
Applicable: Garment Shops, Building Machine Finishing Treatment: Singeing , Calendering
Weight: 450GSM~550GSM Usage: 0.1 To 300um Dust Filter
Filtration Grade: HEPA Filter Maximum Surge Temperature: 210 Degree
Air Permeability: 15-30 M3 / M2.m Filtration Efficiency: 99.9%
High Light:

Calendering Polyester Filter Bag

,

Fiberglass Polyester Felt Filter Bag

,

Nomex Polyester Filter Bag

Polyester Fiberglass Acrylic Nomex PPS Bag Dust Collector Filter Bag Polyester Filter Bag For Steel Plant Dust Collector






Product Description:




Dust filter bags including Nomex Filter bag , PTFE filter bag , Fiberglass Filter bag ,FMS needle felt , PE filter bags , PPS PTFE filter bags ,PTFE Needle Felt ,,etc. The dust filter bags are widely applied in different industrial dust filtration system or air pollution control system dust collector filter elements. Eight production lines keeps our delivery time always in time for every order .



1.The material of the polyeser filter bag:
(1) 100% POLYESTER
(2) ANTI-STATIC POLYESTER
(3) 100% POLYPROPYLENE
(4) HOMOPOLYMER ACRYLIC
(5) NOMEX (ARAMID)
(6) RYTON (PPS)
(7) P-84 (POLYIMIDE)
(8) GLASSFIBER




The application , Industry Baghouse Filtration ,Air pollution control system,


Foundry / Metal Smelting , furnace filter
Asphalt Mixing
Power Generation ,
Waste treatment power generation plant ,
Cement , Gypsum / Lime Processing
Mining.
Carbon Black
Metallurgy
Chemical Plant
furnace filter
Industrial Dust Filter Bag Needle Felt
air filtration filter media PTFE Needle Felt PTFE Filter Fabrics





Specification:



Material Polyester Fiber
Composition Fiber: Polyester; Scrim:Polyester
Grammage 450-600g/m2
Air Permeability 80-100 M3/M2/S
Warp Tension 800-1200N / 5x20cm
Weft Tension 1000-1600N / 5x20cm
Warp Elongation <35%
Weft Elongation <55%
Ventilation Rate 1.0-1.2m / min
Working Temperature Less than 130oC
Normal Bag Size Diameter:120-160mm or customized; Length: 2000-7000mm or customized.
Resistance to Acid Good
Resistance to Alkali Common
Post Treatment Singeing, Glazing, Teflon Coating
Application Cement Plant, Steel Mill, Phosphate Plant, Power Plant







Application and Size of filter bag,Industrial Dust Filter Bag Needle Felt :



Filter Media Working Temperature Application Regular Size (mm )
Nomex Filter Felt 180-10 degree C. Asphalt mixing , metal smelting , Gypsum , Cement plant ,etc . D130 x 2450, D 150 x 3050 , D 160 x 3600 , D150 x 4500
PPS Filter Felt 160-190 Degree C Coal boiler power plant , waste treatment power plant ,etc. D 160x 6000, D127 x 8065
PTFE 100% Filter Felt 240-260 degree C . Waste treatment power plant , D 127 x 3500 , D 130 x 3000
Fiberglass Filter Felt 260-280 Degree C Cement Kiln , Steel plant furnace D 160 x 6000 , 152 x 5000
PTFE memrbane Fiberglass Cloth 260-280 Degree C , Cement kiln , steel plant furnace , carbon black plant D 127 x 36000 , D 130 x 4500
Filter Media Working Temperature Application Regular Size (mm )
Nomex Filter Felt 180-10 degree C. Asphalt mixing , metal smelting , Gypsum , Cement plant ,etc . D130 x 2450, D 150 x 3050 , D 160 x 3600 , D150 x 4500
PPS Filter Felt 160-190 Degree C Coal boiler power plant , waste treatment power plant ,etc. D 160x 6000, D127 x 8065
PTFE 100% Filter Felt 240-260 degree C . Waste treatment power plant , D 127 x 3500 , D 130 x 3000
Fiberglass Filter Felt 260-280 Degree C Cement Kiln , Steel plant furnace D 160 x 6000 , 152 x 5000
PTFE memrbane Fiberglass Cloth 260-280 Degree C , Cement kiln , steel plant furnace , carbon black plant D 127 x 36000 , D 130 x 4500


Polyester Needle Felt Dust Filter Bag is widely used in metallurgical, chemical, building materials, power generation, ceramics, machinery, mining, petroleum, pharmaceutical, food, dye, mining industries etc.It is currently the most ideal filtration materials for the room temperature conditions.



Aramid Filter Bags ,Nomex Filter Bags, Nomex Needle Felt for high temperature Ash filter bags.
Application:
Nomex filter bags are widely used in Asphalt mixing plant ,steel plant , waste incinerators, coking furnaces, kiln furnaces, chemical dry process of flue gas cleaning processes, also using carbon black, powder collection, pneumatic conveying, cement industry and more. When due to chemical attack and hydrolysis causes, Aramid can not be used, PPS Filter Bag can be substituted.

Performance:

1, Good flame retardant and excellent heat function.
2, Excellent performance of strong acid and alkali resistance.
3, Excellent hydrolysis resistance capability and strong chemical stability.

What can we provide for you?
1, Professional and patient reply for the consulations.
2, High qualified products.
3, Competitive price against other suppliers.
4, Professional instruction during the installation.
5, Continuous and stable after-sale service.







Product Show


Fiberglass Acrylic Nomex Polyester Filter Bag Calendering 0



Air filtration filter media


1. Temperature (°C): Continue: 204, Instant: 240
2. Application : pitch mix gas,blast furnace gas in steel factory, gas, tail gas of white char,kiln applications,electric cooker high temperature gas,etc.



PPS Ryton filter bag:
1. Temperature (°C): Continue: 190, Instant: 210
2. Application:waste incinerator,electric station boiler,industry boiler and so on.



P84 / PI filter bag ( Polyimide ),
1. Temperature (°C): Continue: 260, Instant: 300
4. Application:cement kiln,waste incinerator,etc

Fiberglass filter bag , FMS Needle felt :


Air filtration filter media
1.Temperature (°C): Continue: 240, Instant: 260
2.Features:low price compared with other high temperature fibers,and stable size,low
shrinkage rate,high intensity
3.Application:chemistry,steel factory,metallurgy,cement,etc.



Fiberglass combined Felt filter bag:
air filtration filter media , FMS needle felt
1.Temperature (°C): Continue: 260, Instant: 280
2.Features:heavy loads,long life time, reasonable price, strong function etc.
3.Application:polluted air and dust in Iron & Steel factory, Melting factory, Cement factory,Petrol chemistry ,etc.



PTFE 100% filter bag , PTFE Fabrics :
air filtration filter media ,PTFE Needle Felt PTFE Filter Fabrics
1. Temperature (°C): Continue: 250, Instant: 300
2. Features: strong stability, wear resistance, chemical stability, temperature resistance is particularly prominent
3. Application:used in steel, power, waste incineration flue gas filtration and other harsh environments.air filtration filter media





FAQ




1, What kind of filter bags can you provide?

Re, P84, Nomex, PPS, PTFE filter bags are the main products we producve, and PP, DT filter bags are also within our capacity.

2, About the specification, what do you get?

Re, Common specifications like 130x2.45m, 150x4m or 160x6m and we can also design a certain specification for you.
It depends on customers' requirements. You can get more specific information on our web.

3, Can you tell me what certifacation you have?

Re, Yeah, we have got ISO9001 and SGS certification. We pay much attention to our products' quality.

4, What's your payment terms?

Re, Usually in 30% TT in advance and 70% balance against B/L copy.

5, May I ask what kind of after-sale services can you provide?

Re, We offer professional instructions during the installation and oversea service for you if necessarey. For the conplain and claim comes from the problem, we shall take it seriously and give a resonable reply.
