| Place of Origin: | Hefei,Anhui |
| Brand Name: | Anhui Zhongdian |
| Certification: | ISO |
| Model Number: | High temperature filter bags |
| Minimum Order Quantity: | 100 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Pallet , Carton box,knitting bags |
| Delivery Time: | According to the quantity |
| Payment Terms: | T/T, Western Union, L/C, 30% in advance,the balance before loading |
| Supply Ability: | 1000 pcs per day |
| Optional Fabric: | PTFE(Teflon), P84, PPS, Aramid(Nomex), Fiberglass, Fiberglass Blended | Material: | P84(Polyimide) |
|---|---|---|---|
| Applicable: | Plaster Plant,Cement Plant,Waster Incinerator, Manufacturing Plant | Usage: | Industry Dust Collector |
| Weight: | 450GSM~550GSM | Size: | Customized |
| Type: | Pocket Filter, Aramid Filter | Working Temperature: | 260-280℃ |
| Air Permeability: | 200-300(L/m2/s) | Treatment: | PTFE Dipping And Coating |
| High Light: | 450gsm Dust Extraction Filter Bags,1um Dust Extraction Filter Bags,1 micron filter bag dust collector |
||
Features:
1.Excellent steady under high temperature and resistance to acid;
2.P84 can operate continuously,under practical and low acid working conditions at temperature up to 500°F(260°C)
3.High Filtration efficiency,high tensile strength.
4.The complex cross sectional shapes create 30~90% more collection surface area when compared to round or oval shaped fibers.
5.Low back washing pressure,maximum flexibility.
6.The unique tri-lobal fiber structure of P84 provides customers with high effciency filtration,low pressure drop,and reduced cleaning energy.
7.Excellent dust cake release.
8.P84 has irregular,tri-lonal fibers that provide better collection efficiencies and enhanced dust cake release properties.
Description:
Material:P84 filter cloth
Weight: 500~550GSM
Diameter: Φ 120,Φ 130, Φ 135,Φ 138, Φ 152, Φ 158 etc. Size can be customized
LEN: 1000mm~8000mm. Size can be customized.
Specification:
Application Mainly used in Power Plant.
| Product Name | 100%PPS | PPS/PTFE | PTFE Composition | PTFE Composition | 100% PPS With PTFE Membrane | PTFEComposited With PTFE Membrane |
|
| Fiber | PPS | PPS | PTFE+PPS | PTFE+P84 | PPS | PTFE+PPS | |
| Scrim | PPS | PTFE | PTFE | PTFE | PPS | PTFE | |
| Weight(g/m2) | 580 | 600 | 650 | 650 | 580 | 650 | |
| Temperature(℃)Continuous | 160 | 160 | 170 | 260 | 160 | 170 | |
| Temperature(℃)Peak | 190 | 190 | 200 | 280 | 190 | 200 | |
| N/5*20cm)Break Strength Elongation At Break% |
Warp | >900 | >900 | >800 | >800 | >900 | >800 |
| Weft | >1200 | >1200 | >1000 | >1000 | >1200 | >1000 | |
| Warp | <30 | <30 | <30 | <30 | <30 | <30 | |
| Weft | <50 | <50 | <50 | <50 | <50 | <50 | |
| Air Permeability(m3/m2*min) | 10~15 | 10~15 | 10~15 | 10~15 | 2~5 | 2~5 | |
| Applications | Low-sulfur coal, the temperature<160 ℃, lower oxygen content |
Medium-sulfur coal, temperature<165°C(higher instant temperature,higher oxygen content ) |
High-sulfur coal, corrosive and occasions with high oxygen content,improve the use of temperature,oxidation resistance,and cost-effective |
High dust content, higher oxygen content higher temperature, corrosivegas field of flue gas dust. |
Emission Required high efficiency Low-sulfur coal, the temperature<160 ℃, lower oxygen conten | High-sulfur coal, corrosive and occasions with high oxygen content,improve the use of temperature,oxidation resistance, and cost-effective |
|
Package detail and Delivery time
Samples delivery time : 1 ~ 2 days
Normal products : Available stock
LCL orders delivery time : 7~10 days
FCL orders delivery time : 15~20 days
