| Place of Origin: | Hefei,Anhui |
| Brand Name: | PPS Needle Felt PTFE Membrane Filter Bags |
| Certification: | ISO9001-2015 |
| Model Number: | Dust Collector Filter Bags |
| Minimum Order Quantity: | 100pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton or Woven Bag |
| Delivery Time: | 3 days |
| Payment Terms: | T/T, Western Union, L/C, 30% in advance,the balance before loading |
| Supply Ability: | 1000 pcs per day |
| Product Name: | 100-200 Micron Aramid Filter Bags | Seam Treatment: | WS-Fused Seam / SE-Stitched Seam / R-Semi-circle |
|---|---|---|---|
| Applicable: | Cement Plant,Power Plant,Steel Plant,Mining Plant,Asphalt Plant Etc. | Finishing Treatment: | Singeing , Calendering |
| Weight: | 450GSM~550GSM | Usage: | 100-200 Micron Dust Filter |
| Type: | 100-200 Micron Pocket Filter,PPS Filter | Working Temperature: | 120-150 Degree |
| Air Permeability: | 1.68 M3/m2/min | ||
| Highlight: | 450gsm PPS Filter Bags,100 micron PPS Filter Bags,500g/m2 high temperature filter bags |
||
Features:
Provide up to 80% more surface filtration area
Longer lifetime
Higher dirt absorption capacity
Fully welded seams
Special bag filter seal
Full compatibility with the entire Austin filter housing program
Production according to the highest quality standards
Technical Specifications
| Bag size | Filter Area(m2) | Volume(Litre) | Max.flow(m3/h | Diameter | Length |
| P1S | 0.25 | 7.9 | 20 | 7” | 17” |
| P2S | 0.5 | 17 | 40 | 7” | 32” |
| P3S | 0.08 | 1.3 | 6 | 4” | 9” |
| P4S | 0.15 | 2.5 | 12 | 4” | 15” |
| The above dimension meet international standard.We also supply bags filter as per customers’ special requirements. | |||||
Chemical Compatibility
| Filter media | Acids | Bases | Solvents | Oxidizing | Temp. |
| Polyester | Good | Good | Excellent | Limited | 150-170 |
| Polypropylene | Excellent | Excellent | Good | Excellent | 90-110 |
| Nylon | Fair | Good | Excellent | Fair | 150-170 |
| PTFE | Excellent | Excellent | Excellent | Excellent | 250-300 |
Micron/Mesh Conversion Table( Nylon /NMO)
| Micron | 1000 | 840 | 710 | 590 | 500 | 420 | 350 | 300 | 250 | 200 | 180 | 150 |
| Mesh | 18 | 20 | 25 | 30 | 35 | 40 | 45 | 50 | 60 | 70 | 80 | 100 |
| Micron | 100 | 90 | 75 | 60 | 53 | 44 | 37 | 30 | 20 | 15 | 10 | 5 |
| Mesh | 150 | 170 | 200 | 230 | 270 | 325 | 400 | 500 | 625 | 1000 | 1250 | 2500 |
Product Show
1, Modification Filter Bag Features:
1) Material:
Bag body ----- Modification filter cloth
Bag cuff ----- steel-plate,rubber rings and garter spring isavailable
2) Working temperature:
Normal Working Temperature ----- 190-celsius-degree
Peak Working Temperature ----- 240-celsius-degree
3) Weight standard580g/m2
4) Filtration efficiencyup to 99.99%
5) Filtering precision: 120~200L/M2*S.
6) Dimension&Length: As customers' requirement.
7) Quality level: Fine strength&ideal air permeability&big durability.
Application:
1 iron, steel mill, ferroalloy plant, refractory plant, foundry,power plant of flue gas dedusting system etc.
2 Wastes incinerator, coal fired boilers, fluid fluidized bedboiler flue gas filter etc.
3 Asphalt mixing, building materials, cement ceramic, lime andgypsum and other production sites.
4 Aluminum electrolysis, lead and tin, zinc, copper and other raremetal smelting gas filtering,superfine material recovery, liquid andsolid separation.
Construction: filters are carefully fabricated and sized to ensure ease ofinstallation and change-out. Generally, dust collector filter bagsare designed to be mounted and gasketed firmly into place with asnap band, corded cuff, or clamp to ensure dust type seal.
Various coatings and finishes can be applied to either side of the dust collector Polyesater filter bag to enhance cleaning and efficiencies, aswell as prolonging service life. Groundwire, anti-collapse rings,and other options can easily be incorporated into bagconstruction. can custom fabricate various types ofattachments to work with your specific shaker mechanism,whether a loop, eyelet, grommet, or other device.
What we can offer:
1.We can customize filter cloth according to your needs, say, cable ties, velcro, buttonhole.
2.Various filter cloth: plate frame filter cloth, recessed filter cloth, membrane filter cloth, CGR filter cloth, high temperature filter cloth, anti-wear filter cloth etc...
3.Or you can express samples directly.
Shipping way & Package details :
By sea / air / express
Shanghai / Ning Bo/Tianjin
