| Place of Origin: | Made in China |
| Brand Name: | Fiberglass Filter Bag |
| Certification: | ISO9001-2015 |
| Model Number: | Aramid Fabric+glassfiber Dust Filter Bag |
| Minimum Order Quantity: | 100pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton or Woven Bag |
| Delivery Time: | 3 days |
| Payment Terms: | T/T, Western Union, L/C, 30% in advance,the balance before loading |
| Supply Ability: | 1000 pcs per day |
| Product Name: | 25 Micron 50 Micron 100 Micron Metax Nomex Filter Bag For Air Filter | Thickness: | 1.6-2mm |
|---|---|---|---|
| Application: | Building Material Shops, Manufacturing Plant, Printing Shops, Costruction Works | Feature: | 25 Micron 50 Micron 100 Micron High Filtration Accuracy Anti-static Anti-acid And Alkal Anti-abrasion |
| Weight: | 450GSM~550GSM | Usage: | 25 Micron 50 Micron 100 Micron Industry Dust Collector |
| Type: | 25 Micron 50 Micron 100 Micron Pocket Filter, Aramid Filter | Working Temperature: | 120-150 Degree |
| Air Permeability: | 120 L/m2/S | Filtration Efficiency: | < 5mg/Nm3 |
| Highlight: | 1.6mm Polyester Needle Felt Filter Bags,550gsm Polyester Needle Felt Filter Bags,25um non woven filter bags |
||
Description
Filter bag is the core of the dust filter components. The bag filter cost bag filter housing bag polyester filter bag has the strict requirements on design, filter material cutting, woven technology etc. These requirements are very important for the normal operation of the bag filter and convenient maintenance, and it is great significance to enlong the service life of the filter bag.
Filter bag are composed by woven filter material bag body, snap ring, clamp, chain hoist, etc. The rest of the filter bag dust collector and its accessories are the venturi tube, frame, mouth of elastic ring, etc.
The diameter of the filter bag is 115-300mm, length is 2000 - 9000mm, the specifications of the commonly used filter bag is 120 - 160 mm diameter, 2000 ~ 6000mm length.
Product Information
| Article Name | FG350 | FG550 | FG750 | |
| Ingredients | Fiber |
E-glass |
E-glass |
E-glass |
| Loss on ignition | % | 10-13 | 10-13 | 10-13 |
| Weight | g/m2 | 350±15 | 550±15 | 750±15 |
| Thickness | mm | 0.35±0.03 | 0.5±0.2 | 1.0±-0.2 |
| Weave | 1/3 twill | 1/3 twill | Double twill | |
| Permeability | cm3/cm2/s.127pa | 4-7 | 3-6 | 3-5 |
|
Tensile breaking strength(N/2.5cm) |
Warp | ≥1300 | ≥2100 | ≥2300 |
| Weft | ≥800 | ≥1300 | ≥1800 | |
|
Maximum shrink of 90 mins |
Temperature(°C) | 260 | 260 | 260 |
| % | ≤1 | ≤1 | ≤1 | |
| Service Temperature(°C) | Continuous | 240 | 240 | 240 |
| Instant | 260 | 260 | 260 | |
| Velocity of filtration | m/min |
< 0.6 |
< 0.7 |
< 1.0 |
Product Show
Product Feature:
1.High temperature resistance.
2.Good anti-acid/anti-alkali capacity.
3.Excellent anti-abrasion capacity.
4.High filtration efficiency.
5.Good raw material, competitive price.
6.Fast delivery.
7.Size can be customized.
We can support 0.1 micron filter bag / 1 micron filter bags / 5micron filter bag / 0.5 micron filter bag / 25 micron filter bag / 10 micron filter bag / 200 micron filter bag / 50 micron filter bag / 100 micron filter bag.
FAQ
Q: How fast can I get the quotation?
A: We usually quote within 12 hours unless holiday in China, if you can urgent to get the price, you can call us so that we can regard your inquiry priority.
Q: Can I get the samples?
A: yes. The sample can be free of charge. But, the shipping expenses should be paid by the customer. The sample will be issued within 3 days. Custom samples take more time
Q: How long does the production take?
A: Usually the delivery time is 30-45 days after confirming order and detail. Delivery time depending on your purchasing quantity and production season.
Q: Can the logo or company name to be printed on the products or package?
A: Sure.We are able to make your brand label and color box as your requirements. Please contact us to discuss details.
Q: What is your payment term?
A: Our normal payment is T/T 30% deposit, 70% balance should be paid before loading or get a copy of B/L.
Q: How does your factory do regarding quality control.
A: Quality is priority. We will do 100% quality inspection before shipment.
Q: Can you produce according to customers' design?
A: Sure, we are professional manufacturer, OEM and ODM are both welcome.
Q: How I know whether your product can be used in my area?
A: Our filter cloth, filter bag can be widely applied in cement, steel, asphalt and chemical industry, to reduce the emission of dust-content tail gas, thus help controlling the pollution of these industries to the atmosphere.
Delivery time
Samples delivery time : 1 ~ 2 days
Normal products : Available stock
LCL orders delivery time : 7~10 days
FCL orders delivery time : 15~20 days
Shipping way & Package details :
By sea / air / express
Shanghai / Ning Bo/Tianjin
